Product List of One-loop Controller LC500 series
Product List of One-loop Controller LC500 series List
This table can be scrolled horizontally.
| Product | Model | Specifications |
|---|---|---|
| CPU module | LC511 | One-loop controller current output type TOSLINE-S20LP built-in |
| LC512 | One-loop controller pulse output type TOSLINE-S20LP built-in |
|
| Loop display | LD512H | Loop display unit (24 VDC input) |
| I/O | ||
| I/O module | LP03 | Loop I/O current output type |
| LP04 | Loop I/O pulse output type | |
| SAI01 | Analog input 8-channel universal voltage input | |
| SAI02 | Analog input 4-channel 1-5VDC | |
| SAI03 | Analog input 4-channel 1-5VDC with distributor | |
| STC01 | Thermocouple input 8-channel B R S J K T E | |
| SRT01 | Resistance temperature detector 4-channel Pt385/Pt3916 100 | |
| SAO01 | Analog output 8-channel DC 4-20 mA | |
| SAO02 | Analog output 4-channel DC 4-20 mA | |
| SDI01 | Digital input 32 points 24 VDC 5 mA | |
| SDO01 | Digital output 32 points 24 VDC 100 mA | |
| SPI01 | Pulse input 4 points voltage pulse | |
| SPO01 | Pulse output 4 points voltage pulse | |
| Terminal unit | UT5L12 | For LP03/LP04 (Screw terminal unit) |
| UT5A11 | For SAI01/SAO01 (Screw terminal unit) | |
| UT5O11 | For SAI02/SAI03/SRT01/SAO02 (Screw terminal unit) | |
| UT5C31 | For STC01 (Screw terminal unit) | |
| UT5D21 | For SDI01/SDO01 (Connector type terminal unit) | |
| UT5D22 | For SDI01/SDO01 (Terminal unit for G7TC relay) | |
| UT5P11 | For SPI01/SPO01 (Screw terminal unit) | |
| UT5U11 | IO bus extension terminal unit (Screw terminal unit) | |
