Medium Voltage Motor Starter
Medium Voltage Motor Starter
Feature
- Conform to JEM 1225(1996).
- Multi-mode relay for protection and Measurement is available.
- Three tiers construction is available.
- Installed low-surge vacuum contactors.
Specification
Specification List
This table can be scrolled horizontally.
| TYPE FORM | ||
|---|---|---|
| Rated voltage | 7.2(3.6)kV | |
| Rated withstand voltage | Lightning impulse | 45(30)kV |
| Power frequency | 16(10)kV | |
| Rated frequency | 50, 60Hz | |
| Rated bus bar current | Up to 2000A | |
| Rated short time withstand current | Up to 40kA | |
