Density (Consistency) Meter Series
The LQ Series puts you in control of your product quality with high reliability to measure density.
Density (Consistency) Meter Series
Product Introduction
Toshiba's Microwave Density (Consistency) Meter uses microwave phase difference measurement to determine concentrations of solids in the material to be measured flowing through pipes.
It can perform a stable and realtime density (consistency) measurement because this technology is not affected by flow velocity along with fluid, and also is not easily affected by contaminants and low process pressure rate.
As our Density (Consistency) has no moving parts, it is reliable and virtually maintenance free.
Main Applications
Main Applications List
This table can be scrolled horizontally.
| Wastewater Industry | Raw sludge, excess sludge, mixed sludge, digested sludge, dehydrated sludge |
|---|---|
| Paper pulp Industry | Consistency measurement of L-Material (broad-leaved tree-hardwood)/N Material (needle-leaved tree)/hemp pulp, GP (groundwood pulp)/TMP (Thermomechanical pulp)/DIP (deinkling pulp), bleached pulp/unbleached pulp, waste paper, various addictives, pulp sludge, etc. |
| Building material Industry | Consistency measurement in various production processes such as press material and ceiling materiai |
| Food Industry | Consistency measurement in the production processes such as starch, gluten, sugar, evaporated juice and other food slurry Moisture measurement in water such as cream cheese and evaporated juice |
Comparison with the Other Technology
Comparison with the Other Technology List
This table can be scrolled horizontally.
| Measuring method | Microwave | Ultrasonic Distribution | Ultrasonic Pressure Antifoamer | Rotary | Blade | Optic |
|---|---|---|---|---|---|---|
| Measuring principle | Microwave Phase Shift | Ultrasonic Attenuation | Pressure Antifoam Ultrasonic Attenuation | Rotary torque | Shear Stress | Scattering Light Strength |
| No-affection by adhesion | ◯ | △ | △ | △ | △ | △ |
| Continuous measuring (Inline) | ◯ | ◯ | △ | ◯ | ◯ | ◯ |
| Measuring range | Middle to high | Middle | Middle to high | Middle to high | Middle to high | Middle to high |
| Moving part | No | No | Yes | Yes | Yes | Yes |
| Maintenance | ◯ | ◯ | △ | △ | △ | △ |
