FA3100S model 9700
The sales of this product ended in July 2016.
Fusion of High Reliability and Performance
Technology Creating Higher Performance
Xeon processor (Quad Core) built in
High-performance CPU Intel Xeon L5518 (2.13 GHz) is built in for high-speed processing.
* The above comparison is based on Toshiba data, and may differ from the above depending on your system.
High-Speed, High-Performance Chipset and Memory Employed
An Intel 5520 chipset and a high-speed memory with ECC function (6 GB maximum)*1 are employed to offer high-speed data transfer.
＊1 If a main memory of 4 GB or more is installed with a 32-bit OS already installed in your system, the available memory capacity will be about 3 GB
Gigabit Ethernet Interface (3-channel) Included
A gigabit-compatible, 3-channel Ethernet interface is a standard feature.
High Reliability and Support for Stability of Operation
Technology and Quality that Support 24-Hour
Highly reliable, long-life parts are used, based on assumption of 24-hour continuous operation. The individual parts are tested, and the products in the shipment configuration are put to function and temperature tests to determine that they fully satisfy the specifications (in the temperature range of 5 to 40°C) and the high quality requirements.
Visual representation of the 3-lane separate structure
There are two intake fans in the front and one exhaust fan in the rear. Without using CPU cooler fans, the CPU is cooled by direct exposure of the heat sink to the air drawn in by the intake fans. The cooling performance is improved by separating the main heat flows of the major internal parts of the product.
LED Display Module
The LED module provides such functions as displaying initialization status on the LED display panel and indicating hardware operating conditions (cooling fans, lithium battery voltage, and internal temperature) with the RAS status lamps.
You may find the module useful for early identification and separation of failures monitored on the LED display with your application programs.
Good Maintainability and Protection Structure
High Maintainability by Front Access
The hard disks, cooling fans, and lithium battery can be easily replaced from the front of the product.
Front of the Product (Inside the front panel)
Specifications
| FA3100S | model 9700 | ||
|---|---|---|---|
| Single Disk Model | RAID Disk Model | ||
| Processor | Main Processor | Intel Xeon L5518 (2.13GHz) Quad Core | |
| Level 2 Cache | 256KB×4 (256KB/Core) (CPU built in) | ||
| Level 3 Cache | 8 MB (CPU built in) | ||
| Chipset | Intel 5520 | ||
| Main Memory*1 / *2 | Capacity | Min.1GB (1GB×1), Max 6GB (2GB×3) | |
| Auxiliary Storage | Built-in HDD | Options (Refer to the tabel of Optional Hardware Speficications) | |
| Built-in DVD-ROM | |||
| Built-in DVD Super Multi-Drive |
|||
| RAID Compatible | - | RAID 1/5 | |
| Interface | Serial Interface*4 | RS-232C (9-pin D-SUB) x 2ch (rear) | |
| USB Interface*3 / *4 | USBx2ch (front), USBx4ch (rear) (Type A USB 2.0) | ||
| Audio Interface*4 / *5 | LINE IN/LINE OUT/MIC IN (3.5φ mini jack) (rear) | ||
| Ethernet Interface | 10 BASE-T/100 BASE-TX/1000 BASE-T (automatic switching) (RJ45) x 3ch (rear) Wake on LAN (main unit port only compatible) | ||
| Display Interface | Options (Refer to the table of Optional Hardware Specifications) | ||
| DI/DO Interface | DI 4 points, DO 4 points, remote input 1 point (rear) | ||
| Expansion Interface (No. of Slots) |
PCI Express slot*6 /*7 | 4 slots (PCI Express 2.0) | |
| PCI Express (ｘ16) | Full size ×1 slot (exclusive to graphic board) | ||
| PCI Express (ｘ8) | Full size ×2 slots | ||
| PCI Express (ｘ4) | Half size ×1 slot (exclusive to RAID board for RAID Disk Model) | ||
| PCI slot*8 /*9 | Full size ×3 slots (PCI 2.3) | ||
| Input Device | Keyboard | USB 104 keys (Japanese version USB 109 keys selectable) | |
| Mouse | USB (optical) | ||
| Software | OS (Operating System)*11/*12/*13 | Windows® XP Professional Service Pack 3 (English version)(32bit) Windows® 7 Professional (English version)(32bit) Windows® 7 Professional (English version)(64bit) |
|
| RAS Function | Fan stop detection, CPU temperature rise detection Internal temperature detection, Internal voltage detection Memory error detection, PCI bus error detection Digital input/output (DI/DO 4 points each; remote ON/OFF or remote initialize 1 point) Watchdog timer, hard disk monitor (RAID only) Software power off (shutdown), Remote initialize, Remote power on/off Error information save on RAS memory, Operating time monitor function Temperature information trend function, Simulation function, LED display function in initialized state after main unit startup, RAS status lamp function for indicating hardware operating condition (cooling fans, lithium battery voltage, internal temperature, RAID disk) | ||
| Power Supply (Wide Range Power Supply)*18 |
Rated voltage 100 VAC/240 VAC, allowable voltage 85 to 264 VAC, allowable frequency 50 Hz/60 Hz±3Hz | ||
| Electric Power Consumption | Max. 508 W/513 VA | ||
| Dimensions and Weight | 430 (W) x 170 (H)*10 x 460 (D) mm (without projections) Weight: about 17 kg | ||
Optional Hardware Specifications
| Expansion Main Memory*1/*2 | DDR3 SDRAM (DDR3-1066/PC3-8500) 1GB/2GB selectable,with ECC check |
|---|---|
| Built-in HDD (SATA Interface)*14 |
DVD-ROM speed 8x max. (read) / DVD-ROM speed 24x max. (read) / DVD-R speed 8x max. (read) |
| RAID disk model capacity: 160 GB 3 units mountable (hot swap compatible RAID disk) | |
| Built-in DVD-ROM*15 (SATA Interface) |
DVD-ROM speed 8x max. (read) / DVD-ROM speed 24x max. (read) / DVD-R speed 8x max. (read) DVD+R speed 8x max. (read)) / DVD-RW speed 8x max. (read) / DVD+RW speed 8x max. (read) DVD-RAM speed 5x max. (read) / CD-R speed 24x max. (read) / CD-RW speed 24x max. (read) |
| Built-in DVD super multi-drive*15 (SATA Interface) |
DVD-ROM speed 8x max. (read) / DVD-ROM speed 24x max. (read) DVD-R speed 8x max. (write)/speed 8x max. (read) / DVD+R speed 8x max. (write)/speed 8x max. (read) DVD-RW speed 6x max. (write)/speed 8x max. (read) / DVD+RW speed 4x max. (write)/speed 8x max. (read) DVD-RAM speed 5x max. (write)/speed 5x max. (read) / CD-R speed 24x max. (write)/speed 24x max. (read) CD-R speed 24x max. (write)/speed 24x max. (read) |
| Display Interface*16 | Graphic board (DVI-Ix2ch) (rear) (PCI Express) (One DVI-RGB conversion connector provided as an accessory) |
| RAS Terminal Board | DI 4 points, DO 4 points, remote input 1 point |
| RAS Cable | Half pitch 20-pin male at both ends, 2 m max. |
| RAS Terminal Board Mounting Panel |
Simplified type |
| Rack Mounting Parts | For JIS type 19 rack/for EIA type 19 rack |
Installation Environment Conditions
| Installation Environment | Temperature (Operating/Storage) | 5 to 40°C (Temperature near vent) /-10 to 50°C |
|---|---|---|
| Humidity (Operating/Storage) | 20 to 80% RH (no condensation) /10 to 90% RH (no condensation) | |
| Vibration (Operating)*17 | 1.96m or less/s2 (IEC C60068-2-6:9 to 150Hz 1cycle) | |
| (As Packed) | 19.6m or less/s2 | |
| Shock (Operating/As Packed) | 19.6m or less/s2/245m or less/s2 | |
| Dust (Operating/Storage) | 0.3 mg/m3 or less (JEITA-IT-1004A Class B compliant) | |
| Corrosive Gas (Operating/Storage) | Not to be detected | |
| Allowable Instantaneous Interruption Time | 20 ms or less (operating at rated voltage) | |
- *1 Operation will not be guaranteed if you pair other than genuine storage devices for Toshiba industrial computers.
- *2 If a main memory of 4 GB or more is installed with a 32-bit OS already installed in your system, the available memory capacity will be about 3 GB in order to reserve the memory address area for PCI device, etc
- *3 USB interface does not always guarantee the operation of all the USB peripherals.
- *4 Enable/disable can be set using the main unit's BIOS.
- *5 Use mounting units that meet the specifications below.
| Terminal | Maximum Voltage | Remarks |
|---|---|---|
| LINE IN | 1Vrms | Input impedance 10kΩ |
| LINE OUT | 1Vrms | Load impedance 10kΩ to 600kΩ |
| MIC IN | 0.1Vrms | Input impedance 10kΩ |
- *6 PCI Express slot board size (312 mm (L) x 111.15 mm (H) or less) (full size) mountable
- *7 PCI Express slot (167.65 mm (L) x 111.15 mm (H) or less) (half size) mountable
- *8 PCI slot board size (312 mm (L) x 106.68 mm (H) or less) mountable
- *9 Installable PCI boards are 5V key boards and 5V/3.3V shared key boards.(Boards of 3.3V keys only cannot be installed.)
- *10 Shown with 10-mm rubber feet on
- *11 Of the Operating Systems listed here, your specified OS will be installed.
- *12 OS supply period is subject to change depending on the OS distribution period of the OS supplier.
- *13 Pre-installed Windows is licensed.
- *14 Shipment model and drive bay combinations are below
- *15 Pre-shipment option
| Shipment Model | Drive Bay 2 | Drive Bay 1 | Drive Bay 0 | |
|---|---|---|---|---|
| Single Disk Model | - | HDD (option selectable) |
HDD | |
| RAID Disk Model | RAID1 (Mirror) |
Hot spare HDD (option selectable) |
HDD | HDD |
| RAID5 | HDD | HDD | HDD | |
- *16 The graphic card specifications apply only to cases where Windows 7 (64-bit version) is installed.
- *17 Except during operation of auxiliary storage other than HDD
- *18 This model has a power supply with a built-in PFC (power factor correction) circuit. If you are using a UPS (uninterrupted power supply), select a sine wave output type.
