Optical applications and visual inspection technology
Optical technology is applied to the research and development of new products. We design light-emitting devices, optical sensors, and lighting products, and are also developing laser processing and optical inspection systems.
We are developing sensing technology such as laser ultrasonic testing for semiconductor substrate. We are also developing optical sensing technologies including a trace gas analyzer using a quantum cascade laser.
Laser ultrasonic testing
Trace gas analyzer
Laser processing and nanoimprinting technology
We are developing laser processing for welding, cutting, annealing, and 3D printing of semiconductor devices and batteries. We are also developing nanoimprinting for the processing of micro-optical components.
- * This work is supported by manufacturing revolution program centering on 3D additive manufacturing technology organized by METI.
Inspection and Image processing technology
We are engaged in the development of low-cost visual/acoustic automated inspection tools, character recognition and defect classification technologies, and 3D surface profile measurement technologies.
Three-dimensional Profile Inspection
