Toshiba Launches New Line-up of Image Recognition Processors

- To expand its business domain from automotive applications -
28 Feb, 2013
Image of ViscontiTM3 an image recognition processor

TOKYO—Toshiba Corporation (TOKYO: 6502) today announced that it will expand its line-up of ViscontiTM[1] image recognition processors with the launch of the ViscontiTM3 series. The first device in this new series, TMPV7528XBG, is enhanced by the integration of additional processor cores to support various applications, and will extend the range of use beyond automotive systems to industrial applications. Sample shipment will start in  April.

Toshiba initially developed the ViscontiTM series of image recognition processors to advance the creation of camera-based vision systems for automotive applications. The processors recognize traffic lanes, vehicles, pedestrians, traffic signs and more and both the ViscontiTM2 and 3 series devices incorporate image processing accelerators that detect pedestrians with high level detection ratio in real time.

 In addition to these capabilities, the ViscontiTM3 lowers the software-development hurdle for customers  by integrating an ARM 32-bit RISC CortexTM-A9 MPCoreTM (2 cores) dedicated to supporting applications interfacing with the image recognition processor.

With ViscontiTM3, Toshiba will seek to expand the image recognition processor business beyond automotive systems into camera-based vision systems for industrial applications. The company targets annual sales of 2 million ViscontiTM image recognition processors in fiscal 2015.


Advances continue in bringing driver assistance and safety systems to road vehicles. The next impetus will come in the EU, where the European New Car Assessment Programme (Euro NCAP) requires automobile companies to introduce autonomous braking systems next year. These will initially cover other vehicles, and will be extended to include pedestrians in 2016. Initiatives like this are expected to spur 50-100% growth in the global market for image recognition processors between fiscal 2010 and 2015, from 75 to 100 billion yen[2].

Toshiba has played a pioneering role in image recognition processors. It commercialized ViscontiTM in 2004 and the improved ViscontiTM2 in 2011. The new ViscontiTM3 offers improvements in functionality, performance and software development efficiency.

Main Features

1. ARM CortexTM-A9 MPCoreTM

Upwardly compatible with the ViscontiTM2 series. Integration of the ARM CortexTM-A9 MPCoreTM improves connectivity to car navigation systems, smartphones and cloud-based services and makes it easier for customers to implement features during software development.

2. Single/Double-Precision Floating Point Unit (FPU)

Image recognition algorithms and software in embedded image recognition processors must analyze large volumes of image data from the video source, frame-by-frame, in real time, but with limited power consumption and memory resources. Some algorithms for this are difficult to achieve without an FPU, and for this reason Visconti™3 integrates a single/double-precision FPU into each core of the ARM processor.

Outline of New Product

Part number  Sample shipment  Mass production  Product volume
TMPV7528XBG  April 2013  January 2014  100,000
units a year

Main Specifications


Part number  TMPV7528XBG
CPU  ARM 32-bit RISC CortexTM-A9 MPCoreTM
(2 cores with Single/Double-Precision Floating Point Units)
Toshiba original 32-bit RISC CPU
Media embedded Processor (MeP) x1
Image recognition engine  Toshiba's orignal multi-core media processor Media Processing Engine (MPE) x4
Image processing accelerators  Affine transform  1 ch.
Filter  2 ch.
Histogram  1 ch.
Histogram of Oriented Gradients  1 ch. (HOG/CoHOG features)
Matching  1 ch.
On-chip memory Mask ROM: 64 Kbytes
SRAM: 2080 Kbytes
On-chip peripheral functions  Video input I/F  4 ch.
Video output I/F  1 ch.
Main memory
DDR2-533 SDRAM controller
NOR Flash/SRAM controller
PCI Express  1 lane
CAN controller  3 ch.
I2C I/F  4 ch.
UART I/F  5 ch.
SPI I/F  4 ch.
PCM I/F  2 ch.
Timer/Counter  11 ch.
Power supply voltage  Core:1.1V, I/O:3.3V and 1.8V
Operating frequency  Max.300MHz (ARM CortexTM-A9 MPCoreTM) /Max.266MHz (MeP, MPE)
Operating temperature  Ta = -40 ~ 85 °C, Tj = -40 ~ 125 °C
Package  Plastic BGA 516pins, 27mm x 27mm, 1.0mm ball pitch

Visconti TM is a trademark of Toshiba Corporation.
Toshiba data
Cortex TM and MPCore TM are trademarks of ARM Limited.
